在 Docker 容器中部署 Neo4j 集群

企业版

version: '3.8'

# Custom top-level network
networks:
  neo4j-internal:

services:

  server1:
    # Docker image to be used
    image: ${NEO4J_DOCKER_IMAGE}

    # Hostname
    hostname: server1

    # Service-level network, which specifies the networks, from the list of the top-level networks (in this case only neo4j-internal), that the server will connect to.
    # Adds a network alias (used in neo4j.conf when configuring the discovery members)
    networks:
      neo4j-internal:
        aliases:
          - neo4j-network

    # The ports that will be accessible from outside the container - HTTP (7474) and Bolt (7687).
    ports:
      - "7474:7474"
      - "7687:7687"

    # Uncomment the volumes to be mounted to make them accessible from outside the container.
    volumes:
      - ./neo4j.conf:/conf/neo4j.conf # This is the main configuration file.
      - ./data/server1:/data
      - ./logs/server1:/logs
      - ./conf/server1:/conf
      - ./import/server1:/import
      #- ./metrics/server1:/metrics
      #- ./licenses/server1:/licenses
      #- ./ssl/server1:/ssl

    # Passes the following environment variables to the container
    environment:
      - NEO4J_ACCEPT_LICENSE_AGREEMENT
      - NEO4J_AUTH
      - EXTENDED_CONF
      - NEO4J_EDITION
      - NEO4J_initial_server_mode__constraint=PRIMARY

    # Simple check testing whether the port 7474 is opened.
    # If so, the instance running inside the container is considered as "healthy".
    # This status can be checked using the "docker ps" command.
    healthcheck:
      test: ["CMD-SHELL", "wget --no-verbose --tries=1 --spider localhost:7474 || exit 1"]

    # Set up the user
    user: ${USER_ID}:${GROUP_ID}

  server2:
    image: ${NEO4J_DOCKER_IMAGE}
    hostname: server2
    networks:
      neo4j-internal:
        aliases:
          - neo4j-network
    ports:
      - "7475:7474"
      - "7688:7687"
    volumes:
      - ./neo4j.conf:/conf/neo4j.conf
      - ./data/server2:/data
      - ./logs/server2:/logs
      - ./conf/server2:/conf
      - ./import/server2:/import
      #- ./metrics/server2:/metrics
      #- ./licenses/server2:/licenses
      #- ./ssl/server2:/ssl
    environment:
      - NEO4J_ACCEPT_LICENSE_AGREEMENT
      - NEO4J_AUTH
      - EXTENDED_CONF
      - NEO4J_EDITION
      - NEO4J_initial_server_mode__constraint=PRIMARY
    healthcheck:
      test: ["CMD-SHELL", "wget --no-verbose --tries=1 --spider localhost:7474 || exit 1"]
    user: ${USER_ID}:${GROUP_ID}

  server3:
    image: ${NEO4J_DOCKER_IMAGE}
    hostname: server3
    networks:
      neo4j-internal:
        aliases:
          - neo4j-network
    ports:
      - "7476:7474"
      - "7689:7687"
    volumes:
      - ./neo4j.conf:/conf/neo4j.conf
      - ./data/server3:/data
      - ./logs/server3:/logs
      - ./conf/server3:/conf
      - ./import/server3:/import
      #- ./metrics/server3:/metrics
      #- ./licenses/server3:/licenses
      #- ./ssl/server3:/ssl
    environment:
      - NEO4J_ACCEPT_LICENSE_AGREEMENT
      - NEO4J_AUTH
      - EXTENDED_CONF
      - NEO4J_EDITION
      - NEO4J_initial_server_mode__constraint=PRIMARY
    healthcheck:
      test: ["CMD-SHELL", "wget --no-verbose --tries=1 --spider localhost:7474 || exit 1"]
    user: ${USER_ID}:${GROUP_ID}

  server4:
    image: ${NEO4J_DOCKER_IMAGE}
    hostname: server4
    networks:
      neo4j-internal:
        aliases:
          - neo4j-network
    ports:
      - "7477:7474"
      - "7690:7687"
    volumes:
      - ./neo4j.conf:/conf/neo4j.conf
      - ./data/server4:/data
      - ./logs/server4:/logs
      - ./conf/server4:/conf
      - ./import/server4:/import
      #- ./metrics/server4:/metrics
      #- ./licenses/server4:/licenses
      #- ./ssl/server4:/ssl
    environment:
      - NEO4J_ACCEPT_LICENSE_AGREEMENT
      - NEO4J_AUTH
      - EXTENDED_CONF
      - NEO4J_EDITION
      - NEO4J_initial_server_mode__constraint=SECONDARY
    healthcheck:
      test: ["CMD-SHELL", "wget --no-verbose --tries=1 --spider localhost:7474 || exit 1"]
    user: ${USER_ID}:${GROUP_ID}
